PRESSURE GAUGE DOUBLE SCALE 0-100 BAR THREAD G1/2" NG100 CONNECTION:BOTTOM, ValCon®

Double scale pressure gauge according to EN 837-1, NG 100

Specifications:

• Connection thread (GA): 1/2" male thread
• Pressure load (bar): Resting load: 3/4 x scale value, alternating load: 2/3 x scale value, short-term: 1 x scale value
• Nominal size: 100
• Ø cousing front side d1 (mm): 100.0
• Scaling: bar/psi
• H (mm): 135.0
• t (mm): 50.0
• Ø cousing back side d2 (mm): 96.0
• Display range (bar): 0 - 100
• Filling liquid: Glycerin 99.7%
• Accuracy class: 1.0
• Process connection: bottom
• Temperature range (°C): -20°C to +60°C
• Ambient temperature range (°C): -20°C to +80°C
• Material connection: brass
• Housing material: stainless steel
• Glass material: safety glass



Do you have any questions about our pressure gauges? Do you need help choosing the right pressure gauge? Then feel free to contact us by phone at +49 631 351240, via our contact form, by e-mail at shop@loesi.de or via What's App.
