Block-Ball valve 2/2 ways DN10 Pipe 12L 500BAR, ValCon®

Block-Ball valve 2/2 ways DN10 Pipe 12L 500BAR, ValCon®

General Data:

• Versatile fastening possibilities due to integrated, threaded fastening holes (5mm, M6)
• Solderless fittings DIN 2353, light series
• Ergonomically shaped handle
• Precise operation due to optimally adjusted stem.
• Maintenance-free due to a floating ball embedded in the ball
• Preloaded ball
• Galvanized surface

Technical Data:

• Housing: Steel
• Switching shaft: Steel
• Nominal Size: DN10
• Pipe-Ø (mm): 12L
• Port: M18x1,5
• Length (mm): 74,0
• Lever Length (mm): 108,0
• Working p (bar): 500

Download data sheet

Do you have any questions about our ball valves? Do you need support choosing the right one? Then please contact us by phone on +49 631 351240, via our contact form, via E-Mail at shop@loesi.de or via What's App.
