Hydraulic Gear Pump CAP 22190146

CAP 22190146, Lösi Hydraulic Gear Pump, Group 2, 19cm³, SAE "A" Version

Specifications:

• Displacement [ccm/rev]: 19
• Rotation direction: Left
• Shaft: Splined, 9 teeth 16/32 DP
• Centering: 82.55 mm
• Flange: SAE "A"
• Flange hole: 2x Ø11 mm

Technical Data (for continuous use):

• Max. speed: 3500 rev/min
• Min. flow rate: 27.36 l/min
• Max. flow rate: 45.60 l/min
• Max. pressure: 250 bar
• Suction connection Ø19 mm, BCD Ø39.7 mm
• Pressure connection Ø14.2 mm, BCD Ø30.2 mm

Download datasheet for Gear Pumps Group 2

Special features like integrated support bearing or integrated pressure relief valve are available upon request. Please ask us for more information.
