Description

XY 85-0/1, LöSi Hydrostatic Steering Unit

Specifications:

  • Displacement [cm³/rev]: 84
  • Ports: 2 x M8, 14 [.81]
  • Version 5: Open Center-Load Reaction version
  • Mounting Dimension [mm]: 136.3

Technical Data:

  • Rated flow: 9 l/min
  • Rated pressure: 150 bar
  • Without valve pressure
  • Shock valve pressure setting: 200 bar
  • Max. Continuous pressure in Line T: 20 bar
  • Max. Torque with servo amplifying: 3.5 Nm
  • Max. Torque without servo amplifying: 120 Nm
